NB6L14 是一款 3.0 GHz 差分 1:4 LVPECL 扇出緩沖器。差分輸入包含可通過 VT 引腳訪問的內部 50 歐姆終端電阻。此功能允許 NB6L14 接受各種邏輯標準，例如 LVPECL、LVCMOS、LVTTL、CML 或 LVDS 邏輯電平。VREF_AC 參考輸出可用于重新偏置電容耦合差分或單端輸入信號。1:4 扇出設計針對低輸出偏差應用進行了優化。NB6L14 是 ECLinPS MAX 系列高性能時鐘和數據產品的成員。

The NB6L14 is a 3.0 GHz differential 1:4 LVPECL fanout buffer. The differential inputs incorporate internal 50-ohm termination resistors that are accessed through the VT pin. This feature allows the NB6L14 to accept various logic standards, such as LVPECL, LVCMOS, LVTTL, CML, or LVDS logic levels. The VREF_AC reference output can be used to rebias capacitor-coupled differential or single-ended input signals. The 1:4 fanout design was optimized for low output skew applications. The NB6L14 is a member of the ECLinPS MAX family of high performance clock and data products.
